620.A1 Heat Protection Curtain up to 1000 °C

Heat Protection Curtain 620.A1

The 620.A1 heat protection curtain is made from high-quality glass fabric and laminated on one side with a reflective aluminum foil that can withstand radiant heat up to 1000 °C. The silver-reflective surface of the 620.A1 heat protection curtain can reflect up to 90% of incoming radiant heat, effectively preventing heat transfer. This heat protection curtain is ideal as a heat shield for melting and foundry furnaces, protecting people, machinery, components, and goods from high thermal loads, as well as for partitioning heat-exposed work areas.

Our heat protection curtains are custom-designed and configurable in numerous variations to meet specific requirements effectively.

We manufacture our welding curtains exclusively according to your specific requirements – there are no standard dimensions. However, if cut-free or low-waste dimensions are considered, there is a cost advantage. For this, we recommend adjusting the width in full-meter increments, while the height can still be selected individually.

Base Fabric	GT Glass Fabric, 1000 g/m²
Coating	laminated on one side with aluminum foil
Weight incl. Coating	1050 g/m²
Color	silver-shiny
Temperature resistance	up to 1000 °C radiant heat

Technical Characteristics

The 620.A1 heat protection curtains are made from heavy glass fabric, laminated on one side with a reflective aluminum foil.
The reflective aluminum foil can be used for radiant heat up to 1000 °C and reflects up to 90% of incoming radiant heat.
Heat protection curtains from Fingerhuth are made from durable glass fabric, ensuring long service life and stability, even under intense mechanical stress.
Heat protection curtains made from glass fabric are non-flammable, providing high safety even in fire-prone areas.
Heat protection curtains made from glass fabric are resistant to many chemicals, making them suitable for demanding environments such as refineries and chemical plants.
Heat Protection Curtains from Fingerhuth can be custom-made in various sizes and shapes, ensuring maximum flexibility in their application.

Application Examples

Welding Stations in Manufacturing and Assembly Halls: Fingerhuth welding curtains are used to clearly separate welding stations and to protect employees and machinery from sparks, arc radiation, and hot splashes.
Protection in the Automotive Industry: In automotive production, where robots and employees weld and assemble in parallel, Fingerhuth welding curtains serve as barriers between work areas. They protect adjacent production lines and improve workplace safety in factory halls.
Machine Protection in Production Facilities: Along production lines or in welding cells exposed to high thermal loads, welding curtains can be used to protect sensitive machinery and electronics from sparks and heat radiation.
Welding Areas in Metal Processing and Heavy Industry: In heavy industry, particularly in metal processing and plant construction, Fingerhuth welding curtains are used to section off large welding areas and minimize the spread of sparks and heat to adjacent areas.
Storage Areas in Production and Logistics Halls: In production facilities and logistics centers where welding or metalworking is regularly performed, welding curtains can be installed to protect nearby storage areas and reduce the risk of heat damage to materials or products.
